Industrial skylight
Acrylic Smooth Dome
Product
Taylon Skylights’ Tandem Skylight System is designed to deliver maximum daylighting across larger openings by combining two high-performance polycarbonate skylights on a single, continuous tandem base. This configuration provides expanded light coverage, making it ideal for warehouses, manufacturing facilities, and large-span applications where a single unit isn’t sufficient.
Each skylight features durable, high-impact polycarbonate glazing that offers excellent light transmission while standing up to harsh industrial environments. When mounted on the tandem base, the dual units work together to distribute natural light more evenly, reducing shadows and improving overall visibility within the space.
The tandem base is fully customizable and can be fabricated to virtually any size to meet project-specific requirements. This flexibility allows for seamless integration into both new construction and retrofit applications while accommodating unique roof conditions and structural layouts.
Engineered for strength and longevity, the system provides outstanding weather resistance, structural integrity, and long-term performance with minimal maintenance.
Whether for warehouses, manufacturing facilities, or other large-span applications, the Tandem Skylight System from Taylon Skylights maximizes daylighting, improves visibility, and adapts to the specific requirements of virtually any project.
Downloads
Technical
Specifications:
INDUSTRIAL SKYLIGHT TANDEM ACRYLIC SMOOTH DOME
Model: ISATND
Impact rated 200 lbs.
Combustion Classification: CC1
VLT 80%, SHGC 0.58, 100% Diffusion
Benefits:
Can be made to any sizes from:
24" x 24" to 120" x 120"
Available Options:
Dual glazed
Self-flashing base
IR resistance options to reduce SHGC
MAXAIR Venting Base
Features:
High performance and Impact resistant Acrylic
Superior light transmission, 60% VLT, Haze, 100%Diffusion
Curb mount
Architectural grade 6063 T5 aluminum frame with 50-year silicone seal, Santoprene sonic gasket with a 55 durometer, ROHS compliant
Exceeds National Roofing Standards
